Input Capture Interrupts

The input capture (IC) event is a hardware event tied to the logical state of one of the input pins on PORTA. We begin by connecting an external TTL level signal to pins PA2, PA1, or PA0 on PORTA. Recall that these pins always have the "input" direction state. Pins PA0, PA1, and P2 are tied to IC events IC3, IC2, and IC1, respectively. If the logical voltage level on one of these pins changes, then the MicroStamp11 latches the current 16-bit value of the timer register TCNT into the pin's input capture latch register. The logical names for the latch registers associated with input capture events IC1, IC2, and IC3 are TIC1, TIC2, and TIC3, respectively.

We can have the input capture event trigger an input capture interrupt if the input capture interrupt bit (IC1I, IC2I, or IC3I) is set in the control register TMSK1. So, for example, if we set pin IC1I in TMSK1, then the occurrence of an input capture event on pin PA2 will do two things. First it will cause TCNT's current value to be latched into register TIC1. Second, it will cause the program to jump to the interrupt vector associated with interrupt IC1. The first action essentially records the time when the input capture event occurred. The second action jumps to an ISR that performs the computations required to service the IC1 interrupt.

Figure 43 shows the three control registers used by the input capture interrupts. These three registers have the logical names TMSK1, TFLG1, and TCTL2. The register TMSK1 is a control register that is used to "arm the input capture interrupt. Arming the input capture interrupt IC1, for instance, is accomplished by setting bit IC1I in register TMSK1. The register TFLG1 is a status register that can be used to "acknowledge" the servicing of a caught interrupt. We acknowledge a previously caught IC interrupt such as IC1 by setting bit IC1F in register TFLG1. The final register TCTL2 is used to define the "way" in which an input capture event is generated.

Figure 43: Registers for Input Capture Interrupts

It is rather vague to say that the IC event occurs when the input pin's logical state changes, for it is unclear what we mean by a change of state. Does the voltage rising from 0 to 5 volts (a rising edge) or does the falling voltage (from 5 to 0 volts) constitute a "change of state"? In fact, we can identify three types of input capture events based on how we define a state change. We can trigger an event on the rising edge, the falling edge, or on either rising/falling edges. Which edge we choose to use for triggering the IC event can be specified by setting the appropriate bits in the TCTL2 control register.

The bits in TCTL2 that define the edge events for ICn (ALT= or ALT=) have the logical names EDGnB and EDGnA. The effect that setting these bits have on defining the input capture event for the ALT=th pin is given in the following table:

EDGnB EDGnA Active edge
0 0 none
0 1 capture on rising
1 0 capture on falling
1 1 capture on both rising and falling

Input capture events can be used to measure the width of a pulse. This is done by using an input capture event that triggers on the rising edge of a pulse. The ISR servicing this interrupt saves the time when the interrupt was received and then resets the interrupt so it triggers on the falling edge. When the IC interrupt is triggered the next time, we can then subtract the time in TIC1 from the previously saved IC interrupt time to obtain the duration of the pulse. The following code segment shows how this might be done using the IC1 interrupt.

 unsigned int _start_pulse;
 unsigned int _pulse_width;

 #pragma interrupt_handler IC1han();
 void IC1han(void){
   asm(" sei");
   if(TCTL2 == 0x10){
     TCTL2 = 0x20;
     _start_pulse = TIC1;
     TFLG1 |= IC1;
     if(_start_pulse < TIC1){
      _pulse_width = TIC1 - _pulse_width;
      _pulse_width = 65536 - _start_pulse + TIC1;
     TCTL2 = 0x10;
     TFLG1 |= IC1;

 extern void IC1han();
 #pragma abs_address:0xffee;
 void (* IC1_handler[])() = { IC1han };
 #pragma end_abs_address

The preceding ISR uses two globally declared variables, _pulse_width and _start_pulse. In the initialization routine init(), we would first arm the IC1 interrupt by setting the appropriate bit in register TMSK1. In this initialization routine we would also use the instruction TCTL2 = 0x10 to trigger IC1 interrupts on the rising edge of the received pulse on pin PA2. The ISR first checks to see if the interrupt was triggered by a rising edge or a falling edge. If the interrupt was triggered by a rising edge, then we reset TCTL2 = 0x20 to cause the next IC interrupt to occur on a falling edge. We then store the time TIC1 when the first IC1 interrupt occurred in the global variable _start_pulse.

If the ISR is triggered on a falling edge, then we know that _start_pulse already contains the time when the rising edge of the pulse occurred. So all we need to do is difference TIC1 from _start_pulse to get the pulse width _pulse_width. This computation, however, is complicated by the fact that TIC1 is the value in a 16-bit counter TCNT. If this counter overflows after _start_pulse, then it is possible that TIC1 is actually less than _start_pulse. So our ISR needs to check and see if an overflow occurred by checking to see if TIC1 is greater than _start_pulse. If this condition holds, then we merely need to difference _start_pulse from TIC1 to obtain _pulse_width. If an overflow has occurred then TIC1 is less than _start_pulse and we'll need to add 65536 to the difference in order to get the correct value for _pulse_duration.
